Horizontal Bagging Automatic Coding Line
Products Description
The horizontal bagging automatic coding line (compatible with bottle types ranging from 100ml to IL) can be connected to the back end of the horizontal packaging machine to automatically collect and remove data from each bag's QR code (unreadable or duplicate codes). After collection is completed, automatic sorting is performed based on the packaging ratio (number of bottles per box), and then manual packing is carried out; Effectively improving productivity
Performance and characteristics
Horizontal conveyor belt with stable movement speed. Compatible with various horizontal packaging machines, it meets the needs of most enterprises and adopts a high-speed Data Logic DM300 QR code collector with high collection rate. The cylinder type up and down removal mechanism can ensure accurate and stable removal of unqualified products. The operating status and alarm information of the equipment can be reflected in real-time in the system.
Technical parameter
|
Category |
technical parameter |
|
Detection speed |
60~80 bags/min |
|
Bag size |
10~180g |
|
Misdetection rate |
<5% |
|
Exclusion accuracy |
100% |
|
Power supply and power |
220V 50/60HZ 1.5KW |
|
Operating ambient temperature |
0~50℃ |
|
pressure |
0.4~0.6MPa |
|
External dimensions (length x width x height) |
2300x700x1650mm |
|
Total weight |
400KG |
